物理特性/Physical Characteristics

尺寸 Dimensions:

151mm x 142mm x84mm

重量 Weight:

437g

電壓 Voltage:

5V

開機電流 Starting Current：

470mA

待機電流 Stand-by Current：

220mA

工作電流 Work Current：

456mA

性能指標/Performance Characteristics

傳感器像素 Image (Pixels):

1024 pixels (H)x 1280 pixels (V)

光源 Light Source:

Warm Yellow LED

視場角 Field of View:

39°(H) , 28°(V)

旋轉傾斜偏轉 Roll / Pitch / Yaw:

360°, ±65° , ±65°

打印對比度Print Contrast:

20% minimum reflective difference

接口支持 Interfaces Supported:

USB

運動容差Motion Tolerances:

>0.4m/s

解碼能力/Symbology Decode Capability

一維條碼/1-D:

Codabar、Code 39、Code 32 Pharmaceutical (PARAF)、 Interleaved 2 of 5、NEC 2 of 5、Code 93、Straight 2 of 5 Industial、Straight 2 of 5 IATA，Matrix 2 of 5，Code 11、Code 128、GS1-128、UPC-A、UPC-E、 EAN/JAN-8、EAN/JAN-13、MSI、GS1 DataBar Omnidirectional、GS1 DataBar Limited、GS1 DataBar Expanded、China Post(Hong Kong 2 of 5)、Korea Post

二維條碼/2-D:

PDF417, QR code, MicroPDF417, Australian Post, Canada Post,Japan Post, MaxiCode, Codablock, Aztec, Dutch Post, DataMatrix, etc.

用戶環境參數/User Environment

工作溫度 Operating Temperature:

-20°C to 60°C

存儲溫度 Storage Temperature:

-30°C to 70°C

濕度 Humidity:

5% to 95% relative hum idity,non-condensing

抗震性 Shock Specifications:

8 G r.m.s., from 10 to 500 Hz, 2 hours per axis, 3 axes（可承受 70cm 翻倒測試）

環境光免疫 Ambient Light Immunity:

0-100,000 Lux.

解碼范圍/Decode Ranges

Code39(4mil)

0mm-70mm

Code39(5mil)

0mm-100mm

Code39(13mil)

0mm-240mm

Performance may be impacted by bar code quality and environmental conditions
